Features:

High-pressure liquid gas mixing and vortex cutting-edge technology, higher density of Nano Bubbles, non-clogging, and easy to maintain.
With a bubble diameter of 80nm ~ to 200nm, saturated water can be quickly produced with an effective gas-liquid dissolving effect.
24/7 automatic running time, stable performance of Nano Bubble production, higher efficiency, lower energy consumption, and lower noise levels.

Product Introduction:

Our Nano Bubble Generator is CE and ISO-certified and utilizes advanced Nano Bubble Technology; its application range is extensive in different industries and has a huge development potential as the functional properties of Nano Bubble. The bubbles produce an anion explosion with specific disinfection and antiseptic effect while rapidly increasing the dissolved oxygen with high efficiency while saving you energy in the water treatment process. The Nano Bubble Generator could work by itself or in conjunction with our Oxygen or Ozone generator’s corresponding models, which could replace the current aeration equipment.

Nano Bubble Generator for wastewater effluent treatment:

Wastewater treatment: The retention time of Nano Bubbles in the water is ten times longer than that of other forms of aeration. This helps you achieve significant aerobic creation within your application process.

Improve Water Quality:

With other aeration, your dissolved oxygen absorption rate is 3%- 5%; Nano Bubble Generators’ dissolved oxygen absorption rate is 25% or more, which could increase the fish breeding production rate by more than 50%.

Water & Wastewater Treatment

Nano Bubbles have enhanced dissolved oxygen values in water. They last for an extended period, creating a favourable aerobic biological treatment process. Nano Bubbles take the negative electrostatic charge and absorb the positively electrostatic charged pollutants in water to remove them while creating a more efficient flotation separation process. Nano Bubbles are generated without heavy equipment, efficiently making them highly effective while saving labour and operation costs.

Aquaculture:

Nano Bubbles effectively purify and sterilize the water. They enhance fish health and provide faster growth, resulting in less fish feed and drug use—Nano Bubble’s labour and operation costs.

Hydroponics, Aquaponics and Vertical Farming:

The increased dissolved oxygen in the water will accelerate the growth of vegetables, fruit and flowers while creating a higher yield. Nano Bubbles will also enhance the sterilization and disinfection of water. Characteristics of growth by nanobubbles are more significant, plump and tasty.

	Pure 01	Pure 02	Pure 03	Pure 04	Pure 05	Pure 06
Flowrate m³(/h) 50Hz	1	2	6	12	25	55
Hertz (Hz)	50Hz
Power (kW) 50Hz	0.55	1.1	3.0	5.5	11	18.5
Dimensions (mm)	660530800	660530800	850550850	860560850	9156781280	11008801395
Working Temperature (C°)	0-100°C
Treating Capacity(m³)	120	240	720	1440	3000	6600
Bubble Diameter	80nm to 200nm
Gas-liquid Mixing Proportion	1:8-1:12
Gas-liquid	>95%
	Pure 01	Pure 02	Pure 03	Pure 04	Pure 05	Pure 06
Flowrate m³(/h) 60Hz	1	3	8	17	30	60
Hertz (Hz)			60Hz
Power (kW)	0.75	1.5	4	7.5	11	18.5
Dimensions (mm)	660530800	660530800	850550850	860560850	9156781280	11008801395
Working Temperature (C°)	0-100°C
Treating Capacity(m³)	120	360	960	2040	3600	7200
Bubble Diameter	80nm to 200nm
Gas-liquid Mixing Proportion	1:8-1:12
Gas-liquid Dissolving Rate	>95%
